Built by GoKartGod™

Nighthawk Powertrain

$2,399.99 USD
Built To Order Built To Order Item is out of stock Item is unavailable
Power
Mount Configuration
Quantity

Current Lead time is 60-90days for NightHawk Powertrains

Whether you’re working with a Hawk V3, a backyard kart, a Predator setup, or a full race chassis, this powertrain is designed to adapt without turning your project into a full rebuild.

Hawk V3 Platform
Upgrading a gas-powered Hawk V3 to electric?
This kit is built around your chassis, with all required components and brackets to make the switch clean and straightforward.
Minimal welding. No guesswork.
Same build. Completely different speed.

Predator / Honda Clone Setups
Already have a kart, mini bike, or custom build running a Predator-style motor plate?
The motor carrier mounts directly to your existing plate, so you can convert to electric without reworking your entire setup.
Keep what works. Upgrade what matters.

Competition / Custom Chassis
Working with a race kart or custom-built frame?
This kit includes CNC’d aluminum mounting blocks that allow you to bolt the motor directly to your chassis.
Welding may not be required, but weldable brackets are included if you want a permanent solution.
Built for tighter tolerances and higher expectations.

One system. Multiple mounting options.

Because the goal isn’t just to swap powertrains.
It’s to make whatever you’re building faster.



The future starts here

The NightHawk powertrain gives you a complete setup that works right out of the box. Plug it in, mount it, and you are ready. The display is clear, the throttle is smooth, and the parental controls let you cap the top speed for younger drivers. Take the limiter off and the motor delivers instant torque and punchy throttle control. It is fast, responsive, and designed to pull hard. Get ready for an experience like nothing else.

PULSE // 20AH
Kilowatt Rating
15.8 kW Peak
HORSEPOWER
19.6 HP
SPEED
Up to 70 MPH
RANGE - Mixed Riding
60 - 90 Min / 14 - 25 Miles
RANGE - Aggressive/Racing
45 - 60 Mins / 9-14 Miles
Charge time
4 Hrs (5 amp charger)
SPEED CONTROL
3 Drive Modes (10-70 MPH)
SURGE+ // 40AH
Kilowatt Rating
25.7 kW Peak
HORSEPOWER
34.5 HP
SPEED
Up to 80 MPH
RANGE - Mixed Riding
120 - 180 Min / 22 - 45 Miles
RANGE - Aggressive/Racing
120 - 180 Min / 20 - 35 Miles
Charge time
4 Hrs (10 amp charger)
SPEED CONTROL
3 Drive Modes (10-80 MPH)
PULSE // 20AH
Kilowatt Rating
15.8 kW Peak
HORSEPOWER
19.6 HP
SPEED
Up to 70 MPH
RANGE - Mixed Riding
60 - 90 Min / 14 - 25 Miles
RANGE - Aggressive/Racing
45 - 60 Mins / 9-14 Miles
Charge time
4 Hrs (5 amp charger)
SPEED CONTROL
3 Drive Modes (10-70 MPH)
SURGE+ // 40AH
Kilowatt Rating
25.7 kW Peak
HORSEPOWER
34.5 HP
SPEED
Up to 80 MPH
RANGE - Mixed Riding
120 - 180 Min / 22 - 45 Miles
RANGE - Aggressive/Racing
120 - 180 Min / 20 - 35 Miles
Charge time
4 Hrs (10 amp charger)
SPEED CONTROL
3 Drive Modes (10-80 MPH)

Motor

The QS138 90H brushless mid-drive motor delivers exceptional torque and reaches speeds of up to 7000 rpm, all while maintaining outstanding efficiency. It can easily sustain continuous high output without reaching thermal limits. The sealed housing keeps out dirt and moisture, ensuring optimal protection for internal components.

Battery

High-capacity 72V lithium packs available in 20Ah or 40Ah configurations. Both deliver industry leading discharge rates for aggressive acceleration. Sleek black design with integrated BMS that monitors cell health and keeps the pack balanced for long-term reliability. The 20Ah is a great budget-friendly pack that offers solid run time. The 40Ah model delivers 2 times the runtime and offers a maximum output of up to 34.6 horsepower.

Controller

With industry leading reliability, Fardriver controllers get your system powered up and controlled with precision. The ND72450 and ND74680 provide plenty of tire shredding power and have built-in protections for over-temp, over-current, and low voltage keep the system alive even when you're pushing it hard.

Display

Real-time data display mounted in your line of sight. Shows speed, battery voltage, motor temperature, current draw, and system diagnostics while you're driving. Backlit screen stays readable in direct sunlight.

Parental Controls

Our powertrain is the first of its kind to feature a high-speed lockout, allowing parents to limit the kart’s maximum speed and ensure a safer driving experience. This innovative design offers an ideal solution for those who desire a kart capable of exceeding 65 mph while still providing the flexibility to operate at a controlled, child-friendly speed when adult supervision is not available.

Motor mount fitment

1: Upgrade your Hawk V3 kart from gas to electric with our comprehensive upgrade kit, which includes all the necessary mounting brackets and components to get your Hawk V3 electrified quickly and efficiently.

2: For existing karts in need of an electric system, the clone mount option allows you to attach the powertrain to a standard Honda clone-style mount, delivering an incredible system designed specifically for go-karts and enabling you to get powered up fast.

3: For racing chassis requiring a powertrain, our racing mount options enable attachment to standard American and European-style chassis. Weldable mounts for the controller and speed controller ensure the entire system is securely integrated, making conversions straightforward. This is a great system that offering plenty of power and easy installation.
